SMT PCB Magazine Loader

The SMT PCB Magazine Loader is designed for loading of PCBs. All of our SMT magazine Loader is CE compliant.Contact us to order."

Product Description

Hayawin SMT PCB Magazine Loader is designed for loading PCBs. The unit loads your production line automatically by pushing PCBs out of a magazine onto the conveyor of the downstream machine. Connecting with SMT and AI productions line, safety design ensures not to break any PCB when it is pushed and thus reduces defect rate. With high accuracy, automatic counting, and fault alarm functions, it is required for a full range of automatic equipment.



This SMT PCB Magazine Loader is used for loading PCB on the SMT production line.If you want to know more solutions about the SMT assembly process, please go to the web: www.hayawin.com or sent us the email:judyzhu@hayawin.com



SMT PCB Magazine Loader Features:



▹ The machine frame adopts high-strength iron plate, aviation aluminum profile, stable and strong

▹ With safety door lock function, equipment shutdown protection

▹ PLC programmable controller + touch screen

▹ Lifting adopts servo motor + precision ball screw, accuracy ±0.1mm

▹ IO interface prompt function, troubleshooting intuitive, fast and convenient

▹ Loading and unloading magazine pneumatic clamps ensure more accurate positioning of the magazine

▹ Flow Direction: Left to Right or Right to Left optional

▹ Standard SMEMA interface, can be connected online with other equipment



SMT PCB Magazine Loader Technical Specification:

Cycle time

≈8S

Magazine Position Number

2PCS(or customized)

Magazine change time

≈25S

Power supply

220V 50HZ

Air supply and usage

0.4-0.6MPa;≤10L/min

Transport height

950±30mm

Flow direction

Left to Right/Right to Left

Step selection

10-100(adjustable)

Magazine rack slots

50PCS



Model Specification of SMT PCB Magazine Loader:

Model

YS-LD250

YS-LD330

YS-LD390

YS-LD460

Min board size (L*W)mm

80×50

80×50

80×50

80×50

Max board size (L*W)mm

350×250

455×330

530×390

530×460

Magazine size (L*W*H)mm

355×320×565

460×400×565

535×460×565

535×530×565

Dimensions (L*W*H)mm

1270×820×1750

1475×1030×1750

1650×1160×1750

1650×1160×1750



Magazine Line Loading



Magazine line loading refers to the process of loading ammunition into a firearm's magazine. It is an essential step in preparing a firearm for use. Proper loading of a magazine ensures that the firearm can be fired accurately and reliably.



To load a magazine, you will need to insert the ammunition into the magazine in a specific order. This order is typically specified by the manufacturer of the firearm and can vary depending on the type of ammunition being used. Generally, the bullets should be loaded in the front of the magazine, and the magazine should be filled to its capacity.



It is important to ensure that the ammunition is properly seated in the magazine and that the magazine is properly inserted into the firearm. If the magazine is not fully seated, it can cause feeding problems and result in a malfunction of the firearm.



It is also important to follow all safety guidelines when loading a magazine and handling a firearm. Always keep the firearm pointed in a safe direction, keep your finger off the trigger until you are ready to shoot, and be aware of your surroundings at all times.



Overall, magazine line loading is a simple process that is essential for proper firearm function. By following proper loading procedures and safety guidelines, you can ensure that your firearm is ready for use when you need it.
