Fiber Rebar Production Line

Product Description

The fiber composite reinforcement production line has the advantages of high production efficiency, low energy consumption, less labor and strong applicability. It is not only suitable for the production of FRP full threaded reinforcement, but also suitable for the production of glass fiber (GF) and basalt fiber (BF) reinforced reinforcement for civil engineering.

The fiber composite bar produced by Hesheng Longgang pultrusion equipment has good performance, which can not only meet the requirements of the coal industry standard MT / t1061-2008 of the people's Republic of China, but also meet the requirements of the advanced technology standard (bs7861-2007) of developed countries.

Equipment Unit Parameters

Working voltage	380V/50HZ	pressure	0.5-0.8Mpa
Total power	30kW	Unit center height	1000mm
Number of winding heads	1	Number of unwinding heads	1
Temperature control zone	8area	Heating power	4kW/area
Winding / unwinding speed	0-150rpm	Winding diameter	Max32mm
Traction speed	0-1.5m/min	Traction	Max40kN
Track clamping length	1300m m	Track clamping width	215mm
Cutting range	(wide × high)200×85mm	Cutting speed	2850rpm
Tracking cutting stroke	600mm	Fixed length mode	Photoelectric switch
Overall dimension of unit	25000×1850×2000mm	Total weight	About5000Kg
